SINES - surface solar pump - Lorentz


LORENTZ PSK2-CS


  • Category: Surface Solar Pumps

PSk2 is an advanced solar water pumping system designed specifically to use the power of the sun to move water

PSk2 is being used to transform unused land into productive farms.


PSK2-7
CS-F20-5

Max. TDH: 50 m
Max. flow rate: 33 m³/h

 PSK2-7
CS-F12-9

Max. TDH: 90 m
Max. flow rate: 17 m³/h

 PSK2-7
CS-G100-17/2

Max. TDH: 18 m
Max. flow rate: 114 m³/h
PS9K2
CS-G100-22/2

Max. TDH: 20 m
Max. flow rate: 120 m³/h

 PSK2-9
CS-F42-20

Max. TDH: 45 m
Max. flow rate: 65 m³/h

 PSK2-9
CS-F20-7

Max. TDH: 40 m
Max. flow rate: 23 m³/h
PSK2-15
CS-G150-12.5/4

Max. TDH: 25 m
Max. flow rate: 135 m³/h

 PSK2-15
CS-G100-27/2

Max. TDH: 12 m
Max. flow rate: 279 m³/h

 PSK2-15
CS-F65-20

Max. TDH: 45 m
Max. flow rate: 94 m³/h
PSK2-15
CS-F32-60-2

Max. TDH: 80 m
Max. flow rate: 41 m³/h

 PSK2-21
CS-F42-40

Max. TDH: 80 m
Max. flow rate: 63 m³/h

 PSK2-21
CS-F85-20

Max. TDH: 50 m
Max. flow rate: 120 m³/h
PSK2-21
CS-G80-38/2

Max. TDH: 38 m
Max. flow rate: 119 m³/h

 PSK2-21
CS-G150-17/4

Max. TDH: 16 m
Max. flow rate: 306 m³/h

 PSK2-25
CS-G100-40/2

Max. TDH: 40 m
Max. flow rate: 166 m³/h
PS25K2
CS-G200-15/4

Max. TDH: 16 m
Max. flow rate: 457 m³/h

 PSK2-40
CS-G125-40/4

Max. TDH: 40 m
Max. flow rate: 268 m³/h

 PSK2-40
CS-G200-24/4

Max. TDH: 22 m
Max. flow rate: 499 m³/h
Solar pumping systems for reliable Water Supply in Africa

PSk2 controllers are available from 7 to 40 kw. The controller includes the functions of a highly efficient digital inverter, a variable speed drive, all the inputs you will ever need, data logging plus intelligent control over the whole system to give you the most water possible.

PSk2 surface pumps perform equally well in irrigation projects and for wide area drinking water applications where they reliably meet the most demanding requirements. All LORENTZ pumps are pre configured in our PumpScanner App with a simple 3 click setup

PSk2 has eight sensor inputs that allow analogue and digital sensors to be connected. This combination of sensors with the powerful inbuilt software applications allows for full pump control and water specific applications.

The system also has an inbuilt Sun Sensor which measures the available irradiation and then makes decisions of what to do based on the available power. The Sun Sensor also avoids unnecessary stop start cycles which increase pump wear.

PK2k systems provide water into irrigation systems all around the world. Drip, sprinkler, pivot or flood irrigation methods are all fully supported using this system. Very high flows and high pressures can be achieved allowing almost any existing irrigation system can be converted to solar power without replacement.


SINES - Lorentz - submersible solar pump

Installation example showing solar panels, PSk2 controller and PSk2 surface pump - source: https://www.lorentz.de/
